Radioresistance Fluoropolymer Resin / 30Mpa ETFE Resin For Cookware

Radioresistance Fluoropolymer Resin / 30Mpa ETFE Resin For Cookware

Product number:kaxite-f01

Quick Overview: ETFE resin has the advantage of both PTFE&TFE. It has perfect insulativity,thermo chemical,thermo to aging,radioresistance and easily to process.Also with well toughness,hardness,cold flow and creep deformation etc.ETFE has been widely used in aviation,spaceflight,semiconductor,petrochemical heavy-duty,seal material and solar industy.

Send Inquiry

PDF DownLoad

Product Description

Detailed Product Description
Type: ETFE Resin Applications: Cookware
Feature: Radioresistance, Anti-Corrosion Product Name: Fluoropolymer Resin
Tensile Strength: 30Mpa Tensile Elongation: ≥300%



Radioresistance Fluoropolymer Resin / 30Mpa ETFE Resin For Cookware



Quick Detail:


1. perfect  insulativity

2. thermo chemical, thermo to aging,

3. radioresistance

4. easily to process







Description:



ETFE resin has the advantage of both PTFE&TFE. It has perfect insulativity,thermo chemical,thermo to

aging,radioresistance and easily to process.Also with well toughness,hardness,cold flow and creep

deformation etc.ETFE has been widely used in aviation,spaceflight,semiconductor,petrochemical

heavy-duty,seal material and solar industy.







Applications:



Technical Parameter:



Testing

Unit

BC-001

BC-002

BC-003

BC-004

Melt flow speed

g/10min

10~15

10~15

9~12

20~30

Proportion

-

1.70~1.74

1.70~1.74

1.70~1.74

1.70~1.74

Melting point

°c

260~270

260~270

260~270

260~270

tensile strength

Mpa≥

30

30

30

30

tensile elongation

%≥

300

300

300

300

modulus of flexible

Mpa

960

930

910

890

strength of flexible

Mpa

26

25

25

25

impact strength

J/m

No break

No break

No break

No break

liner thermal expansion

10-5/°c

9.3

9.3

9.4

9.4

oxygen index

%

32

32

32

32

thermo chemical resistance

-

Good

2.6

2.6

2.6

Permittivity(102-106HZ)

-

2.6

2.6

2.6

2.6

molding shrinkage

%

1.8

1.8

1.8

1.8



Item Name

Thickness

Application

process method

BC-001

50~80µ

non-stick cookware

Powder coating

BC-002

50~150µ

non-stick coiled material

Powder coating

BC-00201

50~400µ

anti-corrosion machine

Dipping coating

BC-003

2~5mm

reactor,pump,tank

Rotomolding

BC-004

2~5mm

reactor,pump,tank

Rotomolding







PACKING,STORAGE AND TRANSPORTATION



1. The product should be packed in double layers plastic bag, then placed in cardboard drum, 25kgs

    per drum. One drum attached a label, which should be marked the brand, batch No., weight and

    certificate of quality on.

2. The product should be stored in clean, cool and dry warehouse to prevent possible contamination

    such as dust, moisture etc.

3. Exhaust equipment is necessary when processing temperature is high. The temperature should be

    below 390°C.

4. The product are transported according to non-dangerous materials. High temperature, moisture

    and strong shock should be avoided during the transportation.







Competitive Advantage:



1. Excellent Chemical property

2. Virgin and recycled materials available

3. Any sizes available

4. Fast Usually
