Type: | ETFE Resin | Applications: | Cookware |
---|---|---|---|
Feature: | Radioresistance, Anti-Corrosion | Product Name: | Fluoropolymer Resin |
Tensile Strength: | 30Mpa | Tensile Elongation: | ≥300% |
Radioresistance Fluoropolymer Resin / 30Mpa ETFE Resin For Cookware
Quick Detail:
1. perfect insulativity
2. thermo chemical, thermo to aging,
3. radioresistance
4. easily to process
Description:
ETFE resin has the advantage of both PTFE&TFE. It has perfect insulativity,thermo chemical,thermo to
aging,radioresistance and easily to process.Also with well toughness,hardness,cold flow and creep
deformation etc.ETFE has been widely used in aviation,spaceflight,semiconductor,petrochemical
heavy-duty,seal material and solar industy.
Applications:
Technical Parameter:
Testing |
Unit |
BC-001 |
BC-002 |
BC-003 |
BC-004 |
Melt flow speed |
g/10min |
10~15 |
10~15 |
9~12 |
20~30 |
Proportion |
- |
1.70~1.74 |
1.70~1.74 |
1.70~1.74 |
1.70~1.74 |
Melting point |
°c |
260~270 |
260~270 |
260~270 |
260~270 |
tensile strength |
Mpa≥ |
30 |
30 |
30 |
30 |
tensile elongation |
%≥ |
300 |
300 |
300 |
300 |
modulus of flexible |
Mpa |
960 |
930 |
910 |
890 |
strength of flexible |
Mpa |
26 |
25 |
25 |
25 |
impact strength |
J/m |
No break |
No break |
No break |
No break |
liner thermal expansion |
10-5/°c |
9.3 |
9.3 |
9.4 |
9.4 |
oxygen index |
% |
32 |
32 |
32 |
32 |
thermo chemical resistance |
- |
Good |
2.6 |
2.6 |
2.6 |
Permittivity(102-106HZ) |
- |
2.6 |
2.6 |
2.6 |
2.6 |
molding shrinkage |
% |
1.8 |
1.8 |
1.8 |
1.8 |
Item Name |
Thickness |
Application |
process method |
BC-001 |
50~80µ |
non-stick cookware |
Powder coating |
BC-002 |
50~150µ |
non-stick coiled material |
Powder coating |
BC-00201 |
50~400µ |
anti-corrosion machine |
Dipping coating |
BC-003 |
2~5mm |
reactor,pump,tank |
Rotomolding |
BC-004 |
2~5mm |
reactor,pump,tank |
Rotomolding |
PACKING,STORAGE AND TRANSPORTATION
1. The product should be packed in double layers plastic bag, then placed in cardboard drum, 25kgs
per drum. One drum attached a label, which should be marked the brand, batch No., weight and
certificate of quality on.
2. The product should be stored in clean, cool and dry warehouse to prevent possible contamination
such as dust, moisture etc.
3. Exhaust equipment is necessary when processing temperature is high. The temperature should be
below 390°C.
4. The product are transported according to non-dangerous materials. High temperature, moisture
and strong shock should be avoided during the transportation.
Competitive Advantage:
1. Excellent Chemical property
2. Virgin and recycled materials available
3. Any sizes available
4. Fast Usually
