Electrical Insulation PFA Plastic Sheet / PFA Rod Without Poison

Electrical Insulation PFA Plastic Sheet / PFA Rod Without Poison

Product number:kaxite-p01

Quick Overview: PFA Rod is manufactured by molding and extruding method with PFA resin. PFA is the most chemical resistance of all known plastics. It does not age. It has the lowest coefficient of friction of all known solid materials and a wide range of practicable temperature from -180%° C - +260° C.

Send Inquiry

PDF DownLoad

Product Description

Detailed Product Description
Type: PFA Rod Applications: Electrical Insulation
Dielectric Strength: 15Kv/mm Elongation: 280%|260%
Product Name: PFA Plastic Sheet Tensile Strength: 15Mpa|22Mpa



Electrical Insulation PFA Plastic Sheet / PFA Rod Without Poison





Quick Detail:



1.Low water absorption

2.Non firing

3.Non firing in air(oxygen index  more than 95vol.%)

4.No poison

5.With physical inertia

6.High diaphaneity

7.Lowest refractive index in plastic material

8.Weather-assistant

9.Under ozone and sunshine for long time

10.Easy to process for second time





Description:



PFA Rod is manufactured by molding and extruding method with PFA resin. PFA is the most chemical

resistance of all known plastics. It does not age. It has the lowest coefficient of friction of all known solid

materials and a wide range of practicable temperature from -180%° C - +260° C.





Applications:



Lining Bearing pads, seals, and electrical insulation Lining Bearing pads, seals, and electrical insulation,

liner tube, insulator tubing.





Specifications:



Index  number

Unit

Figure

Sheet,   rod  product

Tube  film  product

Density

g/cm3

2.12---2.17

Tensile  strength

Mpa

22

15

Elongation  ratio

%

280

260

Temperature  range

° C

-200-250

Dielectric  strength

Kv/mm

15



Remarks:



We can also produce PFA Rod in other sizes and thickness according to customer's specific requirements.





Competitive Advantage:



1.Excellent Chemical property
2.Virgin and recycled materials available
3.Any sizes available
4.Fast Usually
